NovaCharger

UA Ultra Cherger 36A 16A 32A AX07

From inc.Made in New Zealand

US

$1,395

Color
Power

Cable Length

Connection
Clear selection
- +
SKU: N/A Categories: ,

Which style is suitable for you?

36A

From inc.Made in New Zealand
View More

36A

From inc.Made in New Zealand
View More

36A

From inc.Made in New Zealand
View More

36A

From inc.Made in New Zealand
View More


Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

Charge up to 680 kilometers
in 15 minutes

36A

16A

32A
Charging speed
New Zealand Made
Smart Connectivity
Solar Export Diversion
Carbon Emission Tracking
Home Overload protection
Local Load Management
Colour options
Bio Circular Plastic 4 (Snow, Sand, Stone, Volcanic) 4 (Snow, Sand, Stone, Volcanic) 4 (Snow, Sand, Stone, Volcanic)
Cable Length/Type 70% Bio-based enclosure 70% Bio-based enclosure 70% Bio-based enclosure
IP Rating 4 (Snow, Sand, Stone, Volcanic) 4 (Snow, Sand, Stone, Volcanic) 4 (Snow, Sand, Stone, Volcanic)
Connectivity 70% Bio-based enclosure 70% Bio-based enclosure 70% Bio-based enclosure
Datasheet Model UA-EU-AC07-10-H UA-EU-AC11-10-H UA-EU-AC22-10-H
Input Power Supply 1P+N+PE 3P+N+PE 3P+N+PE
Rated Voltage 230V AC 400V AC
Rated Current 32A 16A 32A
Frequency 50/60Hz
Output Output Voltage 230V AC 400V AC
Maximun Current 32A 16A 32A
Output Power 7KW 11KW 22KW
User Interface Charge Connector Type 2 cable(Type 2 socket optional)
Cable Length 6m
Housing Material PC UL-94V0/PC+ABS UL-94V0
LED Indicator Green/Yellow/Red
RFID Reader Miface ISO/IEC 14443 A
Start Mode Plug&Play/RFID card/App
Communication WiFi WiFi(2.4GHz)
4G yes
Buletooth yes
Ethernet yes
CAN yes
RS485 yes
ESIM optional
Optional OCPP1.6 Json (OCPP2.0 upgraded)
Security and Safety RCD 30mA+6mA DC detection
Ingress Protection IP66
Impact Protection IK10
Electrical Protection Over current protection,Residual current protection,Surge protection,                       Over/Under voltage protection,Over/Under frequency protection,                                    Over temperature protection
Certification CE/TUV
Certification Standard IEC61851-1:2019 IEC 62955:2018 IEC 61851-21-2:2018 IEC 62196
Warranty 2years
Environment Installation Wall-mount/Pole-mount(optional)
Work Temperature ‘-30℃~+50℃
Work Humidity 5%-95%
Work Altitude <2000米
Package Product Dimension 350×196×88mm
Package Dimension 560*375*255mm
Net Weight 4.0kg
Gross Weight 7.0kg
External Package Carton
